CNC 5 Axis milling services & Turn Key Processing

At Pleasanton Tool & Mfg. in Pleasanton, California, we have the equipment and personnel to fabricate any type of part or prototype you may need. We specialize in CNC machining and Wire EDM work using state of the art equipment.

In our cnc maching shop our highly experienced machinist coupled with the traditional manual machines, can take your next project from concept, to prototype, to full production in a very short period of time. Whether it be short runs or production size runs, Pleasanton Tool has your solution.


Milling

Pleasanton Tool & Mfg. offers two types of milling equipment: manual and CNC (computer numerical control). We provide services from 5-axis CNC machines and CNC horizontal/vertical mills to manual Bridgeport™ machines.

CNC 5-Axis Mill

Many parts benefit from significant reduction in setup time and increased accuracy by combining several traditional milling operations into one setup on a 5 Axis mill. We routinely machine parts in 2 operations that would require 5 to 10 setups on a 3 Axis mill. The result is a higher quality product at an economical price.

5 axis
MAZAK VARIAXIS i-500 Workspace diameter: 19.69"
Workspace height: 15.75"
CNC Vertical Mills

Our horizontal and vertical CNC machining centers with 3 and 4 axis capabilities have machine travel up to 80” x 36”. From complicated 3D-surfaced parts to secondary milling operations on turned parts, our machining centers can handle it all. Our team can machine all types of material and a wide variety of parts. With this equipment and our teams combined experience in this department, we rarely have to turn down a job, no matter how intricate it is.

vertical mill
HAAS MINIMILL 2 Machine Travel: X-20" x Y-16" x Z-14"
6,000 RPM Spindle
(3) MAZAK Nexus 510C-II Machine Travel: X-42" x Y-20" x Z-30"
12,000 RPM Spindle
HAAS VF-8 Machine Travel: X-65" x Y-40" x Z-30"
7,500 RPM Spindle
HAAS VF-1 Machine Travel: X-20" x Y-16" x Z-16"
7,500 RPM Spindle
QUANTUM Q-2000V Machine Travel: X-80" x Y-36" x Z-36"
6,000 RPM Spindle
With Tsudakoma 20" Rotary Table
MATSURA 600 Machine Travel: X-28" x Y-16" x Z-18"
6,000 RPM Spindle
CNC Drilling Center
FANUC Robo Drill A-T14iA Machine Travel: X-20" x Y-15" x Z-12"
15,000 RPM Spindle
High Speed, High Accuracy
CNC Horizontal Mills

Our horizontal and vertical CNC machining centers with 3 and 4 axis capabilities have machine travel up to 80” x 36”. From complicated 3D-surfaced parts to secondary milling operations on turned parts, our machining centers can handle it all. Our team can machine all types of material and a wide variety of parts. With this equipment and our teams combined experience in this department, we rarely have to turn down a job, no matter how intricate it is.

CNC Horizontal Mill
HITACHI SEIKI HG400 Machine Travel: X-22" x Y-23" x Z-20"
12,000 RPM Spindle
Multiple Pallet Workstation Capabilities
Prototype Department
(3) CHEVALIER Vertical Mills With PROTOTRAK NC controls
Machine Travel: X-27" x Y-16" x Z-15"
SPORT B3 Vertical Bed Mill With PROTOTRAK NC controls
Machine Travel: X-27" x Y-16" x Z-24"

Turning

Pleasanton Tool & Mfg. offers two types of milling equipment from out cnc machine shop: manual and CNC (computer numerical control). We provide services from 3 Axis CNC Machines to Manual Lathes. We have 0.050'' to 24'' diameter machines.

turning
CNC Lathes

With our HWACHEON HI-TECK 2004, we are able to do secondary mill operations which saves our customer extra costs. We are able to do small collet work on our BAR FEED TMC-15 and up to 24" diameter parts on our NAKAMURA SC-450.

cnc lathe
NAKAMURA SC-450 24" turning diameter, 30" long
NAKAMURA Slant 1 14" Turning Diameter 15" Long
NAKAMURA TMC 15 6" Turning Diameter 10" Long
LNS Quick feed Bar Feeder
HWACHEON Hi-Tech 200A 14" Turning Diameter 16" Long
With Live Tooling for 3 Axis Machining
HAAS TL1 16" Turning Diameter 30" Long
Prototype Department

Pleasanton Tools manual lathe department ranges from a HARDINGE tool room lathe to engine lathes that have the ability to swing 26" diameter parts.

manual lathe
(6) Manual Lathes From Our Precision Hardinge Tool Room Lathe to our 26" Diameter Engine Lathes

Wire EDM (Electronic Discharge Machine)

With our wire EDM's, we have the capability to maintain tolerances of .0001" on any type of material or exotic alloy. We are able to use wire as small as .004" diameter on the toughest materials. When utilizing our micro mini package, our customers get a precision part at an economic price.

machine
(2) FANUC OiC Machine Travel: X-13" x Y-9" x Z-10"
4 Axis Contouring up to 45º
Positional Accuracy to 0.00005"
Wire Sizes from 0.004" to 0.012" Diameter

Precision Lapping

With our Lapmaster pneumatic precision lapping machine, we are able to maintain  a flatness within .0001"  over a 12" diameter surface. If flatness is a concern, look no further.

lapping
LAPMASTER Pneumatic Precision Lapping Machine Lapping Plate 36" x 6.75" ID
Table Speed 58 RPM
Table Drive 5HP, 3Ph, 60 Cycle 220V

Welding

If it's welding you need done, look no further. Pleasanton Tools welders have years of experience with both MIG and TIG, from small jobs to vacuum chambers.

welding
(2) MILLER SYNCROWAVE Tig Welders
LINCOLN 250 Mig Wire Feed Welder
AIRCRAFTER Precision Feed Rotary Table Fixturing Tables up to 72" x 48"

Laser Engraving

We are able to take care of all your needs when it comes to laser marking. From part numbers, serial numbers and barcodes to full graphic designs. With our rotary attachment, we can also do designs on cylinders.

laser engraving
EPILOG FIBERMARK 24 Laser Engraver Engraving Area 24" x 12" x 5"

Inspection Department

Pleasanton Tool is dedicated to consistently meeting or exceeding all of our customer's requirements by the utilization of First Article, In process and final Inspection points. This is done with assistance that range from the numerous surface plates and height gages up to the two CMM's and optical comparator we use for more precise measurements. We also maintain all documentation regarding the projects completed here at Pleasanton Tool  for 10 years.

inspection
ZEISS PRISMO VAST CMM Fully Programmable with CALYPSO 5.0 Software
Machine Travel: X-36" x Y-48" x Z-18"
0.0001" Accuracy
MITUTOYO BH706 CMM CMM Manager 3.0 Software
Machine Travel: X-28" x Y-24" x Z18"
0.0002" accuracy
MICRO-VU Optical Comparator SPECTRA 14F DRO with Q16 Metrology Computer
Auto-Align and Edge Detection
Granite Surface Plates up to 96" x 48"

Clean Area/Assembly

Our clean area is set up for installation of hardware and/or assembly after parts have been precision cleaned. We are also able to clean parts with our ultrasonic cleaners in house.

 Oil Free Assembly Area

We only use nitrogen in our oil-free assembly area. Clean room attire is worn at all times.
person
Ultrasonic Cleaners
BRANSON B5510 Tank Size: 11.5" x 9.5" x 14.5"
Frequency: 40 kHz
BRANSON B1510 Tank Size: 6" x 5.5" x 4"
Frequency: 40 kHz
